Irrigation Systems

Description:

Romtec Utilities designs complete pump stations for irrigation water pumping applications with all structural, mechanical, electrical, and communication systems included. Romtec Utilities designs irrigation pump stations with any required pump technology, including turbine pumps, submersible centrifugal pumps, axial flow pumps, and many more. From deep wells to water intake structures, Romtec Utilities can design and supply your irrigation water system as a single integrated package.

Typical Irrigation Systems Applications:

Pumping Scenarios

Deep Well Pumping
To Treatment
Maintaining Pressure
Pump from Tank to Distribution
Pump from Pond/River
Pump to Discharge

Flow Ranges

Low Flow Lift Stations (50 – 500 gpm)
Medium Flow Lift Stations (500 – 2000 gpm)
High Flow Lift Stations (2000 – 10000 gpm)
Super high flow Lift Stations (10000 – 100000 gpm)

Configurations

- Simplex Pump Configuration
- Duplex Pump Configuration
- Triplex Pump Configuration
- Submersible Pump Configuration
- Jockey Pump Configuration
- Turbine Pump Configuration
- Split-Case Lift Station
- Centrifugal Pump Configuration
- Axial Flow Pump Configuration

Design Options:

Structural

Wet Wells
- Round Precast Concrete 4′ ID to 12′ ID
- Rectangular Precast Concrete 4’x4′ to 10’x24′
- Round Fiberglass 4′ ID to 12′ ID
- Epoxy Spray-On Coatings
Prefabricated Valve Vaults (All Sizes)
Prefabricated Meter Vaults (All Sizes)
Buildings Options:
- Mechanical and Natural Ventilation
- Solar Options
- Interior and Exterior Lighting
- Lighting Panels
- Eye-Wash Stations
- Overhead Cranes Options
- Utility Sinks
- 2-Post, 4-Post, & 6-Post Shelters

Mechanical

Pumps (All Brands Available)
- End Suction Centrifugal
- Vertical Turbine
- Vertical Inline End Suction Pumps
- Vertical Multistage Pumps
- Axial Flow Pumps
- Jockey Pumps
Discharge & System Piping
- Any Material
- Custom Piping Headers
Valve Configurations
- Above-Grade
- Below-Grade
- In-well
Operational Valves
- All Types Available
- All Brands Available
Hatches (Aluminum & Steel)
- Pedestrian Rated
- H-20 Occasional Traffic Rated
- H-20 Full Traffic Rated
- Aircraft Rated
Pressure Gauges
Flow Meters
Pressure Tanks

Electrical

Enclosures (Any NEMA Rating)
- Free-Standing
- Wall-Mounted
- Shelter Mounted
- Interior & Exterior
Control Panels (UL Listed)
- Alternator
- Logic Relay
- Programmable Logic Controller (PLC)
- Touchscreen HMI
- Variable Frequency Drives (VFD)
- Soft Starters
Level Sensing
- Pressure Transducers
- Ultrasonic
- Floats
- Conductive Probes
- Radar
- Air Bubbler
Generators & ATS
- All Brands
- All Fuel Types
