Santa Barbara Cottage Hospital|Santa Barbara, CA|1,095 - 21.5' TDH

jweddell1,000gpm - 5,000gpm, Hospitals, Pacific, Stormwater, Stormwater Runoff

This simple package lift station was designed to handle the medium flows of stormwater at this hospital facility. Submersible centrifugal pumps in a duplex configuration alternate pump starts or can both operate in high stormwater events. The pumps are protected from inflows by an HDPE deflector panel. There is a below-grade electrical junction box in a concrete vault. System controls were designed with a UL listed control panel, float controls for liquid level-sensing, a basic alarm, and an autodialer for telecommunications.

Pacific Gas and Electric Company

PG&E Power Plant|Colusa, CA|300 GPM - 23' TDH

jweddell100gpm - 300gpm, Equipment Washdown, HRSG Blowdown, HRSG Pumping, Industrial, Industrial Process Water featured, Industrial Water, Pacific, Power Generation, Stormwater, Wastewater

These three package lift stations were designed to meet medium flows of industrial process water with added low flows of industrial stormwater and wastewater. Submersible centrifugal pumps in a duplex configuration were specified to meet the peak flows and water chemistry identified for each pump station. UL listed control panels with floats for liquid level-sensing and basic alarms comprise the system controls for the lift stations. These packaged lift stations were integrated into stormwater, processing, and wastewater plans for the new construction of the Colusa Generating Station.

Complete Stormwater Pump Station

International-Matex Tank Terminals|Richmond, CA|770 GPM - 35' TDH

jweddell500gpm - 1,000gpm, Corrosive/ Caustic Pumping, Inlet Outlet Structures, Oil/Water Separators, Pacific, Stormwater, Stormwater Runoff

An IMTT industrial storage facility needed this stormwater pump station to collect runoff and pump it to treatment onsite. The duplex submersible pumps were engineered to handle the expected medium flows of stormwater. The pumps also needed to handle water that could potentially carry oil or other industrial chemicals stored on the site. An above-grade valve assembly used ball valves and check valves that were vertically integrated for easy access. The pump station electrical controls were located on an existing wall in the water treatment area.

Seal of the City of Santa Barbara

City of Santa Barbara | Santa Barbara, CA | 275 GPM - 17' TDH

jweddell100gpm - 300gpm, Control Buildings Shelters, First Flush, Flood Control, Odor Control, Pacific, Stormwater, Stormwater Runoff, Valve Vaults

The City of Santa Barbara needed this packaged pump station to manage low stormwater flows from events that occur during the dry season. Duplex submersible pumps capable of passing a 3-inch solid pump the water into an existing sanitary sewer pressure main and on to treatment. This pump station includes an in-ground valve vault with plug and check valves and stainless steel discharge piping to handle oily or contaminated water conditions. Romtec Utilities supplied the complete electrical controls with liquid level sensing, alarm notifications, pump start and stop cycles, above-grade disconnect stand, and intrinsically safe circuits.

Los Angeles Trade and Technical College

Los Angeles Trade and Tech College|Los Angeles, CA|600 GPM - 26.2' TDH

jweddell500gpm - 1,000gpm, Pacific, Schools, Stormwater, Stormwater Runoff

The expansion of a college campus required this stormwater pump station to handle medium flows of stormwater runoff. To meet the required pumping rate, 7.5 hp Ebara submersible centrifugal pumps were designed in a duplex configuration. This pumping system was designed with dual force mains and check valves integrated in the discharge piping to simplify the engineering for the system. Romtec Utilities provided the complete electrical engineering plans for the UL listed control panel. Floats for primary and backup liquid level-sensing were supplied to give the system added redundancy.
