Romtec Utilities worked on the replacement of a lift station needed for the 4 separate new facilities which will feed into this lift station.
Valley Fine Food Processing|Benicia, CA|45 GPM - 35' TDH
This food processing plant in Benicia, California needed a wastewater lift station to handle combined sewage and process water from the production of pasta. The lift station design included Tsurumi grinder pumps in a duplex configuration. These submersible grinder pumps were included to handle pasta and cheese that occasionally get into the process water. The system electrical controls comprise a standard UL listed panel with float controls for liquid level sensing. The lift station pumps into an existing sewer main and on to treatment.
Santa Barbara Cottage Hospital|Santa Barbara, CA|1,095 - 21.5' TDH
This simple package lift station was designed to handle the medium flows of stormwater at this hospital facility. Submersible centrifugal pumps in a duplex configuration alternate pump starts or can both operate in high stormwater events. The pumps are protected from inflows by an HDPE deflector panel. There is a below-grade electrical junction box in a concrete vault. System controls were designed with a UL listed control panel, float controls for liquid level-sensing, a basic alarm, and an autodialer for telecommunications.
Chino Men's Prison|Chino, CA|135 GPM - 30' TDH
This package lift station was designed to meet the medium wastewater flows of this California prison. Solids-handling pumps in a duplex configuration are protected from cascading influent by a drop bowl. The liquid level-sensing is controlled by a pressure transducer and a float in used for emergency backup. A below-grade valve assembly holds the system’s valves, flow meters, and pressure gauges. An outdoor PLC panel with a basic alarm and an added input for a radio modem comprise the systems controls.
The City of Shafter|Shafter, CA|400 GPM - 28.5' TDH
A suburb of the City of Shafter required a lift station package to repair and rehabilitate an existing wastewater sump. Duplex submersible centrifugal pumps and discharge pipe mounting brackets were fitted to a concrete slab poured in the bottom of the existing manhole. The Romtec Utilities package included the proper components to operate in this 26-foot-deep sump. An outdoor MultiSmart control panel utilizes conductive probes for primary and backup level controls and an autodialer for communications. This retrofit package saved about 60% the cost of a new lift station.
