Romtec Utilities ended up doing three total industrial systems for this project: an Oil Water Separator, a Hot Sump Basin, and a Wash Drains Basin.
Mitsubishi Manufacturing|Sacramento, CA|500 GPM - 15'-15.3' TDH
A Mitsubishi manufacturing plant in Sacramento, California needed two new matching pump stations to handle low-flows of stormwater from an on-site treatment system.
Utica East Ohio Midstream LNG Plant|Kensington, OH|75 GPM - 67' TDH
Utica East Ohio Midstream needed two new pump stations to handle low flows of stormwater runoff at its new Kensington Plant in Ohio. To responsibly contain potentially hazardous stormwater from the topsoil, these pump stations were designed with double-wall fiberglass wet wells with interstitial leak detection. Both pumping systems included corrosion resistant components and sensors due to the potential presences of LNGs in the stormwater runoff. Pumps were engineered with 7.5 hp Ebara pumps in a duplex configuration, and different impellers were specified for each of the two pump stations meet slightly differing head requirements.
Tesoro Corporation|Port Angeles, WA|400 GPM - 30' TDH
A remote Tesoro Corporation industrial site needed this stormwater pump station to handle water discharged from an oil/water separator which processes on-site runoff. Submersible centrifugal pumps were used in a duplex configuration in this shallow wet well. The 7.5 hp Ebara explosion-proof pumps were sized to meet low flow, medium head conditions for stormwater. Check valves and plug valves were integrated into the discharge piping in the well for a simple and cost-effective design. The precast concrete wet well and the access hatch are both pedestrian rated.
Union Pacific Railroad|Cheyenne, WY|100 GPM - 22' TDH
The Union Pacific Depot in Cheyenne, Wyoming needed two new sewer lift stations to replace its existing sewer collection system. Each lift station included three precast concrete vault structures, a wet well, valve vault, and metering vault. Both systems use 2 hp Ebara Vortex® sewage pumps in duplex configurations that are explosions proof rated for Class I, Division I locations. The valve assemblies comprise Val-Matic Cam-Centric® plug valves and Swing-Flex® check valves with pressure gauges. Endress and Hauser PROline® electromagnetic flow meters measure the sewage flows for both lift stations. These in-ground valve and meter assemblies were fitted with heat tracing to provide reliable frost protection with Raychem and Digitrace components.
