Federal Law Enforcement Training Center

Federal Training Center|Bruswick, GA|40 GPM - 15' TDH

jweddell5gpm - 50gpm, Eastern, Military Installations, Municipal Collection, Municipal Lift Station Replacement, Wastewater

This was a true lift station replacement by installing a new package lift station “in the hole” of the removed wet well. Submersible pumps in a duplex configuration were included to meet the low sewage flows from the federal training facility. The system valves were installed in the discharge piping inside the wet well to reduce cost and simplify the system. An outdoor alternator panel handles the controls for this package lift station. It was designed with floats for liquid level sensing and a basic alarm.

U.S. Army Base|Kalaheo, HI|74 GPM - 85' TDH

jweddell50gpm - 100gpm, Military Installations, Mixed Use, Wastewater, Wastewater Featured

Serving the US Army Base, Fort Shafter, this military neighborhood needed a lift station replacement package to be installed adjacent to the existing lift station. The Army and Romtec Utilities configured this submersible centrifugal pump station to pump the medium flow of municipal wastewater. The outdoor control panel utilizes conductive probes for primary and backup level controls and an autodialer for communications. A new generator was installed at grade above an existing generator pit. The owner supplied shelters for the panel and onsite generator.

army post wastewater

USACE Prime Power|St. Roberts, MO|300 GPM - 143' TDH

jweddell100gpm - 300gpm, BABA, Central, Military Installations, Wastewater

These package lift stations were designed to meet the high head pumping requirements for this training facility of the US Army Corps of Engineers. For one station with over 7,000 ft. of 8” force main, 35 hp duplex submersible centrifugal pumps were supplied to achieve the 300 gpm flow rate . The second lift station used smaller, 4 hp duplex grinder pumps to meet its pumping requirements. Outdoor UL listed control panels utilize float controls for level-sensing and soft starters to provide advanced pump diagnostics and to reduce inrush currents. Autodialers were specified for communications.
