California Institute for Men

Chino Men's Prison|Chino, CA|135 GPM - 30' TDH

jweddell100gpm - 300gpm, Corrosive/ Caustic Pumping, Meter Vaults, Pacific, Prisons/Detention Centers, Valve Vaults, Wastewater

This package lift station was designed to meet the medium wastewater flows of this California prison. Solids-handling pumps in a duplex configuration are protected from cascading influent by a drop bowl. The liquid level-sensing is controlled by a pressure transducer and a float in used for emergency backup. A below-grade valve assembly holds the system’s valves, flow meters, and pressure gauges. An outdoor PLC panel with a basic alarm and an added input for a radio modem comprise the systems controls.

Complete Stormwater Pump Station

International-Matex Tank Terminals|Richmond, CA|770 GPM - 35' TDH

jweddell500gpm - 1,000gpm, Corrosive/ Caustic Pumping, Inlet Outlet Structures, Oil/Water Separators, Pacific, Stormwater, Stormwater Runoff

An IMTT industrial storage facility needed this stormwater pump station to collect runoff and pump it to treatment onsite. The duplex submersible pumps were engineered to handle the expected medium flows of stormwater. The pumps also needed to handle water that could potentially carry oil or other industrial chemicals stored on the site. An above-grade valve assembly used ball valves and check valves that were vertically integrated for easy access. The pump station electrical controls were located on an existing wall in the water treatment area.

industrial process pump station

Industrial Pump Station in McIntosh, Alabama- McIntosh Industrial LS

75 GPM
58′ TDH

jweddell50gpm - 100gpm, Corrosive/ Caustic Pumping, Eastern, High Temperatures, Industrial, Industrial Process Water featured, Industrial Water, Municipal, Stormwater Featured, Wastewater, Wastewater Featured

McIntosh, Alabama Industrial Process Lift Station Project Assets DESIGN DRAWINGS PANEL DESIGN SITE-PLANS For this industrial process water lift station, Romtec Utilities partnered with Linde Engineering to design a system for stormwater and process water. The industrial stormwater pump station is for a hydrogen facility in McIntosh, Alabama where most of the inflow will be stormwater along with some condensed steam from process drains. Therefore, the temperature will be high on occasion, but the pumping ...
